Konu: (YENİ) RS-918SSB HF SDR-TRANSCEIVER 5W

[TA5FA]

RS-918SSB HF SDR Transceiver
Transceiver Cost – $350
Shipping Cost – $30
Total Cost – $380

Main Specifications
Frequency Range:
RX: 1.8—30MHz
TX: All HAM HF BANDS
Operating Mode: SSB, CW, FM, AM (RX Only)
Minimum Frequency Step: 1Hz
Antenna Impedance: 50ohm
Operating Temperature Range: -10℃ – +60℃ Frequency Stability:
±1.5PPM @ Power on 5 Minutes (Standard)
±0.5PPM if Optional TCXO Used Operating Voltage: 9-15V DC Operating Current:
RX: ＜450mA; Around 65mA after Power Off (Can be improved at 5mA)
TX: Max. 3A(FULL Power），1.5A(5W Power)
Equipment Size: 190mm(W)﹡70mm(H)﹡40mm(D)
Packing Box Size: 245mm(W) * 125mm(H) * 80mm(D)

Transmitter Specifications
Frequency Band: 160-10m All HF Ham Band
TX Power: Standard 5W (13.8VDC),15W (FULL，13.8VDC)
Modulation Mode: SSB Software Balanced Modulation, 10KHz FM
AM Software Low Modulation (RX only)
Spurious Rejection: ＞40DBC
Carrier Rejection: ＞45DBC
Selectivity: SSB 2.3KHz (-6db)
CW 500Hz (-6db)

IF Frequency: 0
RX Sensitivity: ＞-115dBm
Dynamic Range: ＞95dB
RIT Frequency Tuning Range: ±1KHz
Audio Output: 8ohm, 0.5W

[TA4CS]

  Elinize kolunuza bilginize emeğinize sağlık Mehmet bey teşekkür eder saygılar sunarım.
Aydın'dan 73
